Key Features

PCI Express Gen3 x8
Ultra Low Latency
Supports Up to 1M Connections
Full TCP and UDP offload
Full iSCSI, FCoE offload
Full iWARP RDMA offload
Full NAT offload
EVB, Flex10, VNTag
PCI-SIG SR-IOV
Integrated media streaming offload
HW based firewall in the cloud
Traffic filtering & management
Software Compatible with T4

CHELSIO COMMUNICATIONS INC. Network Interface Cards

2-PORT 10/40GBE LOW PROFILE UWIRE ADAPTER WITH PCI-E X8 GEN 3, 32K CONN. QSFP CO

Mfr # T580-LP-CR SKU 3637674 UPC 897709002684

$428.48 MSRP $830.00 Save 48%

Regular price saves you $401.52 against MSRP.

Available

Product Overview

2-PORT 10/40GBE LOW PROFILE UWIRE ADAPTER WITH PCI-E X8 GEN 3, 32K CONN. QSFP CO

2PORT 10/40GBE LOW PROFILE UWIRE PCI-E X8 GEN3 32K QSFP CONN
Chelsio 2-port 10/40GbE Low Profile UWire Adapter with PCI-E x8 Gen 3, QSFP connector - 10G/40GbE Unified Wire Adapters for Offloaded TCP, RDMA(iWARP), iSCSI, FCoE, DPDK, NVMe-oF, OvS Offload, Packet Classification & Filtering, Virtualization and more
Chelsio 2-port 10/40GbE Low Profile UWire Adapter with PCI-E x8 Gen 3, QSFP connector
10G/40GbE Unified Wire Adapters for Offloaded TCP, RDMA(iWARP), iSCSI, FCoE, DPDK, NVMe-oF, OvS Offload, Packet Classification & Filtering, Virtualization and more

Technical Specifications

Host Interface	PCI Express x8
Product Type	10Gigabit Ethernet Card
Manufacturer Part Number	T580-LP-CR
Form Factor	Plug-in Card
Manufacturer	Chelsio Communications
Product Model	T580-LP-CR
Product Name	T5 Dual Port 10G/40GbE Adapter
Network Technology	40GBase-SR4
Brand Name	Chelsio
Expansion Slot Type	QSFP+
Height	2.7"
Width	6.6"
Media Type Supported	Optical Fiber
Total Number of Expansion Slots	2

Marketing Information

Chelsio's T580-LP-CR is a dual port 40 Gigabit Ethernet Unified Wire adapter with PCI Express 3 host bus interface, optimized for cloud computing, HPC, virtualization, storage, and other data center applications.

The fifth-generation (T5) technology from Chelsio provides the highest 40GbE performance in the industry and dramatically lowers host-system CPU communications overhead with on-board hardware that offloads TCP/IP, iSCSI, FCoE and iWARP RDMA processing from the host system and frees up host CPU cycles for other applications. As a result, the system benefits from higher bandwidth, lower latency, and reduced power consumption.
